### 1 JAVA实现及分析

到这里必须具备的知识储备：对GraphQL有简单的了解，了解Schema的常用类型。
**GraphQL实战(1)-GraphQL介绍 **：https://developer.jdcloud.com/article/2101

这里用一些demo示例来体验GraphQL的执行过程，这只是借助graphql-java实现的java版本。

首先需要引入graphql-java的依赖

```xml
 <dependency>
 <groupId>com.graphql-java</groupId>
 <artifactId>graphql-java</artifactId>
 <version>15.0</version>
 </dependency>
```
#### 1.1 Demo1
第一个demo是官网提供的

```java
import graphql.ExecutionResult;
import graphql.GraphQL;
import graphql.schema.GraphQLSchema;
import graphql.schema.StaticDataFetcher;
import graphql.schema.idl.RuntimeWiring;
import graphql.schema.idl.SchemaGenerator;
import graphql.schema.idl.SchemaParser;
import graphql.schema.idl.TypeDefinitionRegistry;
import static graphql.schema.idl.RuntimeWiring.newRuntimeWiring;
public class HelloWorld {
    public static void main(String[] args) {
        //定义schema文件，直接写在了代码中，包含一个hello的查询方法
        String schema = "type Query{hello: String} schema{query: Query}";
        SchemaParser schemaParser = new SchemaParser();
        //直接加载schema，初始化GraphQL
        TypeDefinitionRegistry typeDefinitionRegistry = schemaParser.parse(schema);
        //加载一份服务端数据
        RuntimeWiring runtimeWiring = new RuntimeWiring()
                .type("Query", builder -> builder.dataFetcher("hello", new StaticDataFetcher("world")))
                .build();
        SchemaGenerator schemaGenerator = new SchemaGenerator();
        GraphQLSchema graphQLSchema = schemaGenerator.makeExecutableSchema(typeDefinitionRegistry, runtimeWiring);
        // 构建一个GraphQL实例，执行graphql脚本
        GraphQL build = GraphQL.newGraphQL(graphQLSchema).build();
        ExecutionResult executionResult = build.execute("{hello}");
        System.out.println(executionResult.getData().toString());
        // Prints: {hello=world}
    }
}
```

这个demo直接加载了schema的内容，构建Graphql执行脚本。这种方式最接近于实际开发的操作。

#### 1.2 Deom2

通过这个demo来看一下一个GraphQL的服务端都做了什么。并对比一下java代码加载GraphQL对象与schema中的GraphQL的联系。

所依赖的对象User

```java
/**
 * ClassName: User
 * Description:
 * date: 2019/6/28 10:38 AM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
@Data
public class User {
 private int age;
 private long id;
 private String name;
 private Card card;
 public User(int age, long id, String name, Card card) {
 this.age = age;
 this.id = id;
 this.name = name;
 this.card = card;
 }
 public User(int age, long id, String name) {
 this.age = age;
 this.id = id;
 this.name = name;
 }
}
/**
 * ClassName: Card
 * Description:
 * date: 2019/6/28 3:25 PM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
@Data
public class Card {
 private String cardNumber;
 private Long userId;
 public Card(String cardNumber, Long userId) {
 this.cardNumber = cardNumber;
 this.userId = userId;
 }
}
```

接下来是demo

```java
/**
 * ClassName: GraphQLDemo
 * Description:
 * date: 2019/6/28 10:40 AM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
public class GraphQLDemo {
 public static void main(String[] args) {
 /*
 定义GraphQL对象,等同于schema中定义的
 type User {
 id:ID
 age:Int
 name:String
 }
 */
 GraphQLObjectType userObjectType = GraphQLObjectType.newObject()
 .name("User")
 .field(GraphQLFieldDefinition.newFieldDefinition().name("id").type(Scalars.GraphQLLong))
 .field(GraphQLFieldDefinition.newFieldDefinition().name("age").type(Scalars.GraphQLInt))
 .field(GraphQLFieldDefinition.newFieldDefinition().name("name").type(Scalars.GraphQLString))
 .build();
 /*
 queryUser : User 指定对象及参数类型
 等同于在GraphQL中定义一个无参方法 queryUser，返回值为User
 queryUser:User
 dataFetcher指定了响应的数据集，这个demo里使用了静态写入的方式
 */
 GraphQLFieldDefinition userFileldDefinition = GraphQLFieldDefinition.newFieldDefinition()
 .name("queryUser")
 .type(userObjectType)
 //静态数据
 .dataFetcher(new StaticDataFetcher(new User(19, 2, "CLC")))
 .build();
 /*
 type UserQuery 定义查询类型
 对应的graphQL为：
 type UserQuery {
 queryUser:User
 }
 */
 GraphQLObjectType userQueryObjectType = GraphQLObjectType.newObject()
 .name("UserQuery")
 .field(userFileldDefinition)
 .build();
 /*
 Schema 定义查询
 定义了query的root类型
 对应的GraphQL语法为：
 schema {
 query:UserQuery
 }
 */
 GraphQLSchema qlSchema = GraphQLSchema.newSchema().query(userQueryObjectType).build();
 //构建一个GraphQl对象，执行逻辑都在此处进行
 GraphQL graphQL = GraphQL.newGraphQL(qlSchema).build();
 //模拟客户端传入查询脚本，方法名queryUser，获取响应值为 id name age
 String query = "{queryUser{id name age}}";
 // 执行业务操作逻辑，获取返回值
 ExecutionResult result = graphQL.execute(query);
 System.out.println(result.toSpecification());
 }
}
```
这里对应的sehema应该是这样的：

```bash
#对应的User定义如下
schema {
    #定义查询
    query: UserQuery
}
#定义查询类型
type UserQuery {
    #指定对象以及参数类型
    queryUser : User
}
#定义对象
type User {
    #!表示非空
    id: ID!
    name:String
    age:Int
    card:Card
}
type Card {
    cardNumber:String
    userId:ID
}
```

**可以看出：**
schema的结构层级是：schema > UserQuery > User

schema中定义的是操作类型，UserQuery下定义的是操作方法，而User对应的是GraphQL的对象，此对象应该对应于java中一个相同的对象

**以上demo实现中有两点是实战中不可取的：**
schema的加载方式，应该以读取本地配置的形式加载
dataFetcher的数据加载，demo中是静态写死的方式，实战中应该是动态加载的数据
接下来从这两点改进

#### 1.3 demo3

首先在resources目录下创建一个user.graphqls的文件
```bash
#对应的User定义如下
schema {
    #定义查询
    query: UserQuery
}
#定义查询类型
type UserQuery {
    #指定对象以及参数类型
    queryUser : User
    queryUserById(id:ID) : User
}
#定义对象
type User {
    #!表示非空
    id: ID!
    name:String
    age:Int
    card:Card
}
type Card {
    cardNumber:String
    userId:ID
}
```

```java
import clc.bean.Card;
import clc.bean.User;
import graphql.ExecutionResult;
import graphql.GraphQL;
import graphql.schema.GraphQLSchema;
import graphql.schema.idl.RuntimeWiring;
import graphql.schema.idl.SchemaGenerator;
import graphql.schema.idl.SchemaParser;
import graphql.schema.idl.TypeDefinitionRegistry;
import org.apache.commons.io.IOUtils;
/**
 * ClassName: GraphQLSDLDemo
 * Description:
 * date: 2019/6/28 11:19 AM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
public class GraphQLSDLDemo {
 public static void main(String[] args) throws Exception {
 //读取graphqls文件
 String fileName = "user.graphqls";
 String fileContent = IOUtils.toString(GraphQLSDLDemo.class.getClassLoader().getResource(fileName), "UTF-8");
 //解析文件
 TypeDefinitionRegistry typeDefinitionRegistry = new SchemaParser().parse(fileContent);
 RuntimeWiring wiring = RuntimeWiring.newRuntimeWiring()
 .type("UserQuery", builder ->
 builder.dataFetcher("queryUserById", environment -> {
 //解析请求参数，根据业务返回结果
 Long id = Long.parseLong(environment.getArgument("id"));
 Card card = new Card("123456", id);
 return new User(18, id, "user0" + id, card);
 })
 )
 .build();
 GraphQLSchema graphQLSchema = new SchemaGenerator().makeExecutableSchema(typeDefinitionRegistry, wiring);
 GraphQL graphQL = GraphQL.newGraphQL(graphQLSchema).build();
 String query = "{queryUserById(id:15){id,name,age,card{cardNumber,userId}}}";
 ExecutionResult result = graphQL.execute(query);
 System.out.println("query: " + query);
 System.out.println(result.toSpecification());
 }
}
```

项目源码：https://gitee.com/chengluchao/graphql-clc/tree/master/graphql-java/src/main/java/com/clc/demo

**从demo升级成实战项目需要做的内容：**
schema与java代码分离，可以通过读取文件的形式将schema加载到系统中；
动态处理GraphQL的请求参数，并随之生成对应的响应

可能大家已经发现，入参和出参都需要服务端编码实现解析。
**其实graphql-java做的事情是很有限的，主要作用如下：**
维护schema的结构
根据GraphQL的脚本需要，过滤响应结果

其他很大一部分的工作都需要自己实现的。

### 2 spring Boot 实现
接下来分享一下在Spring Boot中对GraphQL的应用
首先创建一个Spring Boot的项目

#### 2.1 POM依赖
```xml
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
 <modelVersion>4.0.0</modelVersion>
 <parent>
 <groupId>org.springframework.boot</groupId>
 <artifactId>spring-boot-starter-parent</artifactId>
 <version>2.3.4.RELEASE</version>
 <relativePath/>
 </parent>
 <groupId>com.clc</groupId>
 <artifactId>boot</artifactId>
 <version>0.0.1-SNAPSHOT</version>
 <name>boot</name>
 <description>Demo project for Spring Boot</description>
 <properties>
 <java.version>1.8</java.version>
 </properties>
 <dependencies>
 <dependency>
 <groupId>org.springframework.boot</groupId>
 <artifactId>spring-boot-starter</artifactId>
 </dependency>
 <dependency>
 <groupId>org.springframework.boot</groupId>
 <artifactId>spring-boot-starter-web</artifactId>
 </dependency>
 <dependency>
 <groupId>com.graphql-java</groupId>
 <artifactId>graphql-java</artifactId>
 <version>15.0</version>
 </dependency>

 <dependency>
 <groupId>org.projectlombok</groupId>
 <artifactId>lombok</artifactId>
 <version>1.18.4</version>
 </dependency>
 </dependencies>
 <build>
 <plugins>
 <plugin>
 <groupId>org.springframework.boot</groupId>
 <artifactId>spring-boot-maven-plugin</artifactId>
 </plugin>
 </plugins>
 </build>
</project>
```

#### 2.2 创建schema

接下来就是创建一个schema的文件，来写graphql的定义，这里还用之前的例子。resources下创建一个user.graphqls。
```bash
#对应的User定义如下
schema {
    #定义查询
    query: UserQuery
}
#定义查询类型
type UserQuery {
    #指定对象以及参数类型
    queryUser : User
    queryUserById(id:ID) : User
}
#定义对象
type User {
    #!表示非空
    id:ID!
    name:String
    age:Int
    card:Card
}
type Card {
    cardNumber:String
    userId:ID
}
```

#### 2.3 Java实现
##### 2.3.1 数据操作对应的java对象

```java
package com.clc.boot.bean;
import lombok.Data;
/**
 * ClassName: User
 * Description:
 * date: 2019/6/28 10:38 AM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
@Data
public class User {
 private int age;
 private long id;
 private String name;
 private Card card;
 public User(int age, long id, String name, Card card) {
 this.age = age;
 this.id = id;
 this.name = name;
 this.card = card;
 }
 public User(int age, long id, String name) {
 this.age = age;
 this.id = id;
 this.name = name;
 }
}
package com.clc.boot.bean;
import lombok.Data;
/**
 * ClassName: Card
 * Description:
 * date: 2019/6/28 3:25 PM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
@Data
public class Card {
 private String cardNumber;
 private Long userId;
 public Card(String cardNumber, Long userId) {
 this.cardNumber = cardNumber;
 this.userId = userId;
 }
}
```

##### 2.3.2 解析GraphQL的核心类
```java
package com.clc.boot.graphql;
import com.clc.boot.bean.User;
import com.clc.boot.bean.Card;
import graphql.GraphQL;
import graphql.schema.GraphQLSchema;
import graphql.schema.idl.RuntimeWiring;
import graphql.schema.idl.SchemaGenerator;
import graphql.schema.idl.SchemaParser;
import graphql.schema.idl.TypeDefinitionRegistry;
import org.springframework.context.annotation.Bean;
import org.springframework.stereotype.Component;
import org.springframework.util.ResourceUtils;
import javax.annotation.PostConstruct;
import java.io.File;
import java.io.IOException;

/**
 * 实现功能：将GraphQL对象载入待Spring容器，并且完成GraphQL对象初始化的功能
 *
 * @author chengluchao
 */
@Component
public class GraphQLProvider {

private GraphQL graphQL;

@Bean
    public GraphQL graphQL() {
        return graphQL;
    }

/**
     * 加载schema
     *
     * @throws IOException
     */
    @PostConstruct
    public void init() throws IOException {
        File file = ResourceUtils.getFile("classpath:user.graphqls");
        GraphQLSchema graphQLSchema = buildGraphQLSchema(file);
        this.graphQL = GraphQL.newGraphQL(graphQLSchema).build();
    }
    private GraphQLSchema buildGraphQLSchema(File file) {
        TypeDefinitionRegistry typeRegistry = new SchemaParser().parse(file);
        GraphQLSchema graphQLSchema = new SchemaGenerator().makeExecutableSchema(typeRegistry, buildWiring());
        return graphQLSchema;
    }

private GraphQLSchema buildSchema(String sdl) {
        TypeDefinitionRegistry typeRegistry = new SchemaParser().parse(sdl);
        RuntimeWiring runtimeWiring = buildWiring();
        SchemaGenerator schemaGenerator = new SchemaGenerator();
        return schemaGenerator.makeExecutableSchema(typeRegistry, runtimeWiring);
    }

/**
     * 业务实现，demo版
     * 如果是开发实战，这一点的设计是重点，需要考虑如何根据graphql中定义的方法来执行java代码
     *
     * @return
     */
    private RuntimeWiring buildWiring() {
        RuntimeWiring wiring = RuntimeWiring.newRuntimeWiring()
                .type("UserQuery", builder ->
                        builder.dataFetcher("queryUserById", environment -> {
                            Long id = Long.parseLong(environment.getArgument("id"));
                            Card card = new Card("123456", id);
                            return new User(18, id, "user0" + id, card);
                        })
                )
                .build();
        return wiring;
    }
}
```

接下来是GraphQL的入口：

```java
package com.clc.boot.controller;

import graphql.ExecutionResult;
import graphql.GraphQL;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;

/**
 * ClassName: GraphQLController
 * Description:
 * date: 2019/6/28 5:38 PM
 *
 * @author chengluchao
 * @since JDK 1.8
 */
@RequestMapping("graphql")
@Controller
public class GraphQLController {
 @Autowired
 private GraphQL graphQL;
 @RequestMapping("query")
 @ResponseBody
 public Object query(@RequestParam("query") String query) {
 ExecutionResult result = this.graphQL.execute(query);
 return result.toSpecification();
 }
}
```

测试：
```
127.0.0.1:8080/graphql/query?query={ user: queryUserById(id:15){id,name,age,card{cardNumber,userId}}}
```

```json
{
    "data": {
        "user": {
            "id": "15",
            "name": "user015",
            "age": 18,
            "card": {
                "cardNumber": "123456",
                "userId": "15"
            }
        }
    }
}
```
源码地址：https://gitee.com/chengluchao/graphql-clc/tree/master/graphql-springboot

这里实现了graphql在spring-boot中的应用，由于解析graphql到业务执行还不够自动化，所以此例子还是一个demo级别

------------
###### 自猿其说Tech-JDL京东物流技术发展部
###### 作者：中台技术部-基础平台组 程路超
